Pocket Sized Mobile Phone Amplifier !!!!

Even though I do not know from experience- (as I do not play the guitar)- I have heard from many of my friends that one of the biggest pains of an electric guitar is the need to hook it up to an amp to hear actual electric guitar sound. Thats not a problem with the Milli-AMP!

Product pitching aside, this is a pretty neat project for somebody with beginner's electronics skill that can follow a schematic. I will state now that the circuit is not of my own design, but is a modified Little Gem Mk II circuit from runoffgroove.com. I would recommend checking out the site for some other pretty cool music-related schematics. Even though the circuit is not mine, the design of the enclosure and the charging circuit is of my own creation.

The Milli-AMP uses a bridged ML386N-3 amplifier circuit to produce in the neighborhood of two watts output power. It runs of a rechargeable 9 volt battery, which provides about an hour of full volume play per charge. At two watts, the Milli-AMP is more powerful than any commercially available amp (that I know of) of its size; its size being a very pocket able 2.25 by 3.5 by 1 inches (roughly). Volume is controlled by the volume pot on the guitar, and this adversely controls distortion as well. For an idea of what it sounds like, see the last step of this instruct able .

SIMPLE 9V IR DETECTOR !!!!

This is a great, simple project to make a small and robust 9V IR detector. It can be used to seek out security cameras that use infrared light to "see" or to check if your remote control is still working.

For this project you will need:
-A 9V battery clip with a flat cover made of plastic
-A 9V battery
-LED (any color although it should be clear in order to see it better)
-330 ohm resistor (orange-orange-brown-gold or silver)
-Infrared Photo transistor
-pref board (see 2nd picture)
-double sided mounting tape
-wire
-needle nose pliers
-wire sniper
-dremel or hack saw to cut pref board
-clear epoxy-like glue
-Soldering equipment:
      -soldering iron
      -solder with flux core

Appliance Control using your TV/DVD remote !!!!

Hello,

            Friends I am bask with my New Tremendous Circuit which Control your appliances using you TV or DVD remote. Actually I have already Posted a Circuit which have also same funcation as it Works. But This Time its too fast responsive then older one.



    Actually We are using a Decade counter IC CD4017 which is Very popular for counting purpose. Its a simple and Fast IC we Compare to Last circuit which was based on bistable multivibrator . But this time its Turn to Decade Counter.

Download Project PDF {DOWNLOAD}


Circuit Diagram is Shown Below :

Circuit Construction
                 The original circuit diagram for this project was published in the May 2005 issue of the Electronics For You magazine. The circuit diagram below is mostly the same. It uses a TSOP1738 IR receiver module at the input side to receive the 38 KHz frequency IR pulses from the remote control. Under normal condition, the output pin of the IR module is at logic High, which means the transistor T1 (BC557 PNP) is cut-off and its collector terminal is at logic Low. The collector of T1 drives the clock line of the CD4017 decade counter.

                 Now lets see what happens when somebody faces a TV or DVD remote towards the TSOP1738 and presses any key on it. The TSOP 1738 module receives the train of 38 KHz IR pulses from the remote, that makes its output to oscillate too. These pulses are inverted at the collector of T1, which finally go to the clock input of the decade counter. The arriving pulses could increment the CD4017 counter at the same rate (38 KHz), but because of the presence of the RC filter circuit (R1 = 100K, C1 = 10 uF) between the collector and the ground, the train of pulses appear as a single pulse to the counter. Thus, on each key pressing, the CD4017 counter advances only by a single count. When the user releases the key, the C1 capacitor discharges through the R1 resistor, and the clock line is back to zero. So every time the user presses and releases a key on the remote, the CD4017 counter receives a single pulse at its clock input.

WORKING PRINCIPLE
Initially, when the circuit is just powered on, the Q0 output of the CD4017 decade counter goes high. The counter increments for each low-to-high going pulse arriving at its CLK pin (14). When the first pulse arrives, Q0 goes Low and Q1 is turned High. This activates the relay and the AC appliance connected to it is turned on. The status LED connected to Q1 also glows to indicate the appliance is switched on. When the user presses a key again, the second pulse arriving at the CLK line increments the counter by 1. This makes Q1 back to Low (which means the relay is deactivated and the appliance is turned off) and Q2 is pulled High. Since Q2 is wired to the Reset input, the second key press actually brings the CD4017 IC back to the power-on-reset conditions with Q0 High. Thus, it basically operates as an ON/OFF toggle switch controlled with any key of an infrared remote.

      The power supply for the circuit can be derived from the mains AC itself using a step down transformer and a bridge-rectifier circuit. For +5V power supply, the LM7805 regulator IC can be used as shown below.

           I have enclosed the circuit board with the power supply inside a wooden box as shown in the pictures below. The electrical appliance to be controlled can be powered from the AC outlet at the front side.

Question Paper for Electronics & Communication Polytechnic Students Every Year !!!!!

Electronics and Communication Previous year Question Paper !!!

• Fift Semester [5th SEM]          {Download}
• First Semester [1st SEM]        {Download}
• Third Semester [3rd SEM]      {Download}
• Second Semester [2nd SEM]   {Download}
• Fourth Semester [4th SEM]     {Download}



Syllebus of 5th SEMESTER {Download}

NOTE : If any One find Any more Question Paper  or Note. Then Plz Comment on !!! We will move our attention toward it. Otherwise This Post will Keep On updating By New Question Papers and Note Only of ECE branch.




How to Know Email Address of Facebook User !!!!!

Simplest method ever :-

I use this method and it works. no software or installation needed.

1. you must have yahoo account
2 login to your yahoo mail.
3.go to contact – then choose import email from facebook (it suck all your friend email address into your contact list)
4. export yahoo csv. download/save it.
5. open csv in ms excel.

Hit thanx and tell if dis works for you.


There you go. if you have any other method; that work better please share.thanks!

                                             Add facebook contacts in gmail

Simply import exported .csv into gmail and you have all of your Facebook friends email addresses in your Gmail contacts list.and any other that supports import contacts from .csv.

Nokia 800 Sun – Mobile Features Specs n Images



                               Nokia is expecting to release its new device in coming November. The device will work on both 2G and 3G network. Nokia 800 Sun looks like a perfect gadget wrapped up with all elegancies. Nokia 800 Sun is holding 3.7 inches AMOLED capacitive touchscreen with Anti-glare polarizer facility like its name which helps to reflect the sun light and protects from scratches. Nokia 800 Sun price may be high because of its wider storage of pre installed memory and few others accountable characteristics.





• Processor 1.4 GHz

• Manufacturer Nokia

• Model Name 800 Sun

• Announced Not officially announced yet

• Availability Not officially announced yet, November 2011 (Expected)

• Status Coming soon

• Available Colors Black

• Form Factor Candybar

• Keyboard Touch Sensitive

• OS and Processor

• OS Microsoft Windows Phone 7.5 Mango

• Processor 1.4 GHz processor

• Network

• 2G GSM 850 / 900 / 1800 / 1900 MHz

• 3G HSDPA 850 / 900 / 1700 / 1900 / 2100 MHz

• Physical Characteristics

• Touchs Size 3.7 inches

• Colors 16M colors

• Memory Internal 16 GB storage , Expandable No

• GPRS Yes

• EDGE Yes

• WLAN Wi-Fi 802.11 b/g/n

• 3G HSDPA 14.4 Mbps; HSUPA 5.76 Mbps

• Bluetooth v2.1 with A2DP+EDR

• USB v2.0 microUSB

• Infrared Port No

• GPS Yes, with A-GPS support

• Java

• Java MIDP 2.1

• Camera Yes

• Secondary Camera Yes

• Games Yes + downloadable

• FM No

• Music Player (Supported Formats) MP3/WAV/eAAC+/WMA

• Video Player (Supported Formats) MP4/H.264/H.263/WMV

• Battery Standard Li-Ion mAh battery







Tikona Broadband – Tariff Plans – Wireless Broadband Internet Service

                        Tikona Broadband

Tikona Digital Networks (TDN) provides next generation wireless broadband services for home and enterprise customers in India.Tikona Broadband provides Wireless Broadband to Home (BTH) service , that is wireless Internet access at home without need of any wireless router .The WPA2 and 802.1x security features are deployed for the Tikona Wireless Broadband service. A complimentary licensed anti-virus package worth Rs.1,500 is also provided with the Tikona Wireless Broadband to Home service that protects data on customer PC from spyware, viruses , and malware.
To connect multiple PCs wirelessly pay Rs.75 per month or Rs.1,500 for lifetime .

                              Tikona Broadband 2 Mbps Plan

Now browse the Internet at speed of 2 Mbps with tariff of just Rs.499 per month for 5000 MB data usage .

Introduction FAQ :
1. About Tikona Digital Networks Ltd (TDN)
Tikona Digital Networks (TDN) is an all-India ISP (Internet Service Provider) specializing in wireless broadband service. The service is powered by 4th Generation OFDM & MIMO technologies.

2. What is Broadband?
It is an always on internet connection that can provide a download speed of >=256 kbps.

3. What is High Speed Internet?
It is an always on internet connection that can provide a download speed of up to 256 kbps.

4. What are the advantages of Broadband?
Broadband allows you to complete your task of downloading or uploading large sized files or multimedia content web pages much faster than a dial up internet, thereby saving your valuable time, and giving you a superior internet experience.

5. What are possible broadband applications?
One can use broadband for applications like travel ticketing, online banking, stock trading, Voice over IP (VoIP), video chat over the Internet, or download multimedia content like music, movies and games to name a few.

6. Can I access Tikona WI-BRO service while travelling or outside my home?
You cannot access this service while traveling. However, you may receive coverage in common areas of your society such as lawns, club house and swimming pool if your society/ building has enrolled into the WI-BRO campus program of TDN.

7. What are the advantages of Tikona WI-BRO service over other wired internet connection?
The service comes with many benefits however important being.

2 Mbps plans with Bill Limit.
No Spoiling of Home/Office interiors as no cabling required.
All Home solution to connect multiple PCs wirelessly.
Greater Security: Freedom from risks of self installed Wi-Fi
Click to connect dialer for easy yet secured access to the internet service.
Enhanced security of your PC as Anti- Virus bundled with basic service.

                                                  Service Availability/Ordering

1. Where all is Tikona's WI-BRO service available?
Tikona WI-BRO service is available in various metros and non-metros across India. We are constantly adding new cities to our service footprint. To know more, visit the Service Availability Section of our website. For more info please call 1800 20 90044

2. How can I find out whether Tikona WI-BRO service is available in my area?
Please call 1800 20 90044 and provide your area pincode & building name along with your contact details. Our representative will get back to you regarding the service availability in your area.

3. What is the delivery time of your service?
If your building is Tikona WI-BRO enabled, then we can deliver the service within 3 days from receipt of SRF and submission of all supporting documents.

In case your building is Non RFS then we shall be happy to work with your building authorities to make the building Tikona WI-BRO enabled in the shortest possible time.

4. What set up do I need at my residence or office in order to subscribe to Tikona's WI-BRO service?
Your PC/laptop should support the following

Intel PIV 2 GHz or higher.
512 MB RAM
Minimum 2 GB free Hard disk space at the time of installation.
OS: Win 7, Win 2K,Win XP, Win Vista.
Ethernet LAN Card /Port (10/100Base T) with TCP/IP support
Browser Options: IE 6.0 & above, Mozilla Firefox 3.0 & above, Opera, Google Chrome
5. What are the modes of payment along with the order?
You can make upfront payment through cheque/DD in favor of "Tikona Digital Networks Pvt. Ltd" along with the order. The upfront charges will be applicable as per the tariff plan. Any cash payment will not be accepted.

6. Are charges paid along with the SRF (Subscriber Registration Form) refundable incase I cancel the order.
You shall be entitled for a full refund if TDN is not able to deliver service within agreed period.
However no refund is applicable subsequent to Service provisioning

7. Can I know the status (or progress) of my order?
Yes, you can request for status of your Tikona WI-BRO Service order at 1800 20 90044.The status update shall be provided by the concerned delivery manager of your area.

8. What is the process of Service Delivery?
As a first step, we check the service availability then request for your SRF alongwith necessary documents and the upfront payment. Your User name & Password is sent to your mobile no through SMS & email once your SRF is successfully processed. Please do not lose this information or share it with anybody including Tikona’s Installation executive or the Tikona Care officer. Our Installation Engineer will visit your residence or office to complete the installation, as per the appointment fixed with you.

9. Can I reuse the Password which is issued at the time of service delivery?
No, the Password is for one time use only, and allows you to access the service in combination with the USER ID for the first time. It is mandatory to change your password at the time of first log-in.

10. What do I do incase I face any issue with my password?
Please call up at Tikona Customer Care & help us with the necessary information and we will provide you a new password on your mobile number.

11. Is there any other charge besides installation charges that I need to pay?
A CAT 5 cable is provided at no extra cost if the subscriber needs to connect his PC on the Ethernet interface. Cable laying through casing and capping will be charged @ Rs.10 /Feet. This will be over and above installation charges and needs to be paid directly to Tikona Authorized Partner’s installation executive.

   Product & Tariff

1. What speed is offered by Tikona WI-BRO for its service?
Following speed will be offered under various plans of Tikona WI-BRO service

Fixed Monthly Charge plans with 2 Mbps download speed
Fun Unlimited Plans(FUL) with 2 Mbps bonus bandwidth for first few hundred MBs, post which unlimited usage on 256 Kbps, 512 Kbps, 750 Kbps and 1 Mbps download speed.
Circuit Breaker Plans with 2 Mbps download speed.
Premium unlimited usage plan with 2 Mbps download speed.
Annual plans with speed of 256 Kbps & 512 Kbps download speed.
2. Which plan from Tikona WI-BRO service is ideally suited for me?
Our website consists of a plan selector which helps decide suitable plans depending upon users usage pattern.

3. What is the advantage of Fun Unlimited Plans?
The Fun Unlimited plans come with bonus bandwidth of 2 Mbps for first few hundred MBs.

4. What is the advantage of a Circuit Breaker (CB) Plans?
The CB plans provides high download speeds with bill limit feature.

5. Explain the concept of Circuit Breaker (CB) plans?
In case of circuit breaker plans as soon as your bill reaches the maximum bill value, your charging stops. Your service however, continues to work, although at a reduced speed. The original speed is restored automatically upon receipt of bill payment. Alternatively, you can choose to make an ad hoc payment ahead of your regular bill payment date, to enjoy full speed service. In circuit breaker plans usage during the 'reduced speed' period is not charged.

6. Does Tikona WI-BRO service come with value added services?
Tikona WI-BRO comes with value added services such as
ALL Home/Office solution: To connect multiple PCs wirelessly with a charge of Rs.75/month or Rs.1500 for lifetime (Optional)
Parental Control Utility: Comes with monthly incremental charge of Rs 65/month or Rs.650/year. (Optional)
Wireless USB adaptor: Rs 50 per month/unit or Rs. 800 for lifetime/unit for desktop/laptop not equipped with wireless interface. (Optional)
Static IP: Comes with charge of Rs.1000/ year. (Optional)
Basic Anti Virus: Complementary with Tikona WI-BRO service.

7. How does your service help me save money?
Antivirus bundled worth Rs.1,500 is provided with the service.

                                                                             Billing

1. Do you have Pre-paid or Post-Paid plans?
Currently Tikona WI-BRO service is available in Post-paid plans only

2. Where and how can I pay my bill?
Online Option -(Visit www.tikona.in >> Click on My Account >> Enter User Id and Password >> Click on make payment >> Click on Payment >> Click on make payment).
Net banking (14 Banks-more being added)
Credit Card/Debit Card (MasterCard, VISA)
You can drop a cheque in any ICICI Bank ATM check drop box.

3. Can I view my bill online?
Yes, you can view the bill summary online on selfcare portal. (Visit www.tikona.in >> Click on My Account >> Enter username and password>>Click on Bill details)

4. What happens if I do not pay the bill by due date?
If the payment is not made by due date, you will be charged an interest on overdue invoices from the due date until payment made @ 2 % per month, subject to a minimum charge of Rs. 25.

5. How does the bill reach me?
You get the Tikona WI-BRO e-bill on the email id registered with us.
Physical copy of the bill to your registered billing address (likely to be discontinued in future).

6. I need to understand the various charges on my Tikona WI-BRO service?
Please call up Tikona Customer Care on 1800 20 94276 to understand the various charges.

7. Do we allow balance carry forward of bundled usage?
In current plans we do not allow carry forward of unused bundled usage.

8. I need a duplicate bill/I have not received my bill. How do I get it?
For duplicate bill, please call up Tikona Customer Care & ask for a duplicate bill. As a policy we don’t provide Duplicate Physical Bill copy. Based on your request a duplicate bill will be forwarded to your email address as provided in the SRF.

9. When do I pay the bill if I am on a long term (quarterly, half yearly or annual) plan?
You need to pay the plan charges, installation charges (if applicable) alongwith service tax in advance. Service will be provided on realization of the cheque.

                                                                     Service Usage

1. When can I start using my internet service?
We recommend that you use the service after our installation engineer visits your home/office to complete the installation procedure & demonstrates how to use the service.

2. From which devices can I access Tikona WI-BRO service?
You can access Tikona WI-BRO service from a PC or a Laptop. (Refer recommended configuration in Service Availability/ Ordering section).

3. How do I access my Tikona WI-BRO service?
For Windows Users
Launch Dialer > Select Profile > (Ethernet, All Home) > Enter Username & Password > Launch Browser
For MAC Users
Launch Browser > Enter Username & Password

4. I have an @ll Home/Office solution, how many PC/Laptops can be used in this solution?
A subscriber can register maximum four PCs in CB49, CB299, CB499, FUL499, FUL599, FUL799, FMC599, FMC799, QFUL1499, QFUL1799, QFUL2399 eight PCs in FUL1399, FMC1499, FMC2499, HFUL2999, HFUL3599, HFUL4799, AUL5000, AUL6000 and ten PCs in UL3499 in @ll home solution.

5. Will my bill be very high if I am connected for all the time?
No. You will be charged only for the upload/download of data transfer and not based on the time for which you are connected to the internet. However we recommend you to log out when you do not want to use internet as activities such as streaming, flash, auto updates, virus on your PC etc can result in unintended data transfers from your PC.

6. Do you provide any online portal to manage my account?
Yes. Online Self Care Portal is available to manage your account & many more aspects of Tikona WI-BRO service. This portal is accessible after you log into the service. Alternatively you can access the same portal through our website (Visit www.tikona.in >> Click on My Account >> Enter User Id and Password)

7. What are the things I can do from my Online Self Care portal?
Online Self care portal provides facilities, such as
Service Request
Change password - Option to Change password.
Session History - Check your internet session history on day to day basis.
Anti-Virus - Gives the license key details along with activation details.
MAC Addresses - Gives the MAC ID's registered against the User account.
Billing and Payments

Invoice Summary - Shows historical invoice summary details
Payment List - Shows historical payment details.
Make Payment - Option to make an online payment though Credit Card/Net banking.
Subscriber Profile

Personal information - Provides the user user's subscription details such as Username, address etc.
Service Information - See Plans Details along with any VAS that you have subscribed.
Ask for Help
Email - This section helps to write your feedback/concern to Tikona Customer Care.

8. How do I know what is the actual speed of my Tikona WI-BRO service?
There is a facility to measure the speed at which your broadband connection is working. Once you log in you can click on the speed test icon on the dialer (for windows user) or Go to http://www.speedtest.tikona.in (for MAC users) to check the connection speed. The speed is displayed upto TDN’s ISP node.

9. Can I shift my connection from one location to another location (within city or across city)?
If the new location where you would like to shift has adequate signal strength, then you can shift the connection. We will need your new billing address proof.

10. Can I change my tariff plan?
You are allowed to change your tariff plan to any other tariff plan of your choice as per the terms & conditions of the plan. For changing the plan please contact Tikona Customer Care on1800-20-94276 or write an email to customercare@tikona.in

11. Will I get signals in entire home?
If you have subscribed to a plan that provides bundled @ll home service, then you can get
Wireless coverage (upto 1000 Sq. feet) in home area.
For large homes (more than 1000 Sq. feet area), customized solution can be extended as per your request.

12. How can I change my billing address?
Send an email to customercare@tikona.in and provide your Username, present billing address, new billing address and a scanned copy of new billing address from your registered email Id.
Fill up the section for billing address change provided on the back of your bill statement. Attach a photocopy of your new billing address proof and send it to our city office (address to SA/SD Head).


CPE Related

1. Which CPE's/modem do I need to access Tikona's WI-BRO service?
Modem for Tikona WI-BRO service will be supplied by TDN depending upon the nature of installation and service subscribed.

2. Do I own the CPE provided by TDN?
No. The CPE is provided on a ‘Right to use’ basis and it is a property of Tikona Digital Networks Pvt. Ltd. In case of service discontinuation subscriber shall return the modem/wireless USB adaptor in working condition. Rs.1500 per CPE will be payable if subscriber retains or returns the modem/wireless USB adaptor in non working/damaged condition.

3. What is ALL Home/Office solution; does TDN provide the Wireless Wi-Fi modem/router?
ALL Home/Office solution
Extends Tikona WI-BRO service wirelessly throughout your home/office without spoiling your interiors.
Is built using latest MIMO technology that improves network coverage up to two times over conventional home Wi-Fi.
Is enabled with highest level WPA2 security with AEC encryption technology. This makes the entire solution substantially safer than self installed Wi-Fi.
The @ll home/Office CPE is provided by Tikona as a part of @ll home service delivery.

4. My laptop/ PC does not support Wi-Fi; can TDN help me?
Yes, you can opt for Wireless USB adaptor available for a nominal extra monthly charge of Rs. 50 or a Life time rental of Rs.800/-.

5. Will Tikona do the initial configuration of Tikona WI-BRO service on my PC/Laptop?
Yes, Tikona's authorized installation executive will do the initial configuration of Tikona WI-BRO service as a part of the installation process.



Technical

1. Is Tikona’s WI-BRO service secure?
Tikona WI-BRO is far more secured than other self installed Wi-Fi services because of the following
ikona WI-BRO uses state-of-the-art WPA2 encryption standard (128 bit key versus 40 bit key used in earlier standards) for data transmission and 802.1x authentication for clients.
assword is set by the end user/subscriber directly through a Self Care Portal.
Access is permitted only from devices whose MAC IDs are allowed by the end user/subscriber.
Compulsorily requires modem/dialer for accessing Tikona WI-BRO service.

2. What best practices need to be adopted by a user while accessing Tikona WI-BRO service?
Keep the Modem at optimum signal strength.
Ensure that the modem is never displaced from the location where it was installed to receive the optimal signal strength.
Ensure that the modem is powered ON and the rightmost LED is steady green before usage.
Please ensure that your laptop wireless button is switched ON, incase connecting through @ll Home service.
Remove Proxy settings
Change your password regularly.
Never share your password with anyone including any Tikona representative
Logout when you are not expecting to use the service for an extended duration.

Tikona Broadband Unlimited Plan

Download unlimited data with Tikona Broadband Wireless Internet service starting with Rs.499 per month @ 256kbps speed .

Customize your Nokia Phone (5800, 5233, etc) With Modded FW !!!

              NOKIA PHONE CUSTOMIZATION THROUGH FLASHING METHOD !!!!


                          Everyone Wants a Customised Phone and So many wants to have their phones loaded with many features which nokia isnt able to provide and so we Mod the firmwares for you all to provide you a firmware with all the useful and loaded features but it isnt possible for each of you to flash your phone easily as it is a risky task and needs some guidance so here is a guide for all of the users .


1) First Download the Navifirm from HERE
2) Second Download The JAF tool along with Pkey From HERE
3)Extract the Navifirm Anywhere with the use of winrar or any zip archiver and Run it (You should
   have Dotnet Framework 2.0 installed in You pc).
4)Download The original firmware from your phone.



5)Install Nokia pc suite if you dont have it installed already (Cable Drivers Are installed with them

   and needed)

6)Now if you have already downloaded the firmware from the navifirm Paste all the files to

   C:\Program Files\Nokia\phoenix\products\RM-XXX\  (RM-XXX means RM of your phone.

   It may be RM-625, RM-428 etc.If your RM is RM-625; Then make the folder as

   ('RM-625')

               (IF you have 64 bit OS then paste the files to C:\Program Files (X86)\Nokia\phoenix\products\RM-XXX\
7)Now Extract Nokia Flash tools.rar and Install the JAF tool and now copy the Jaf_nok4models.ini

   file and Pkey_emulator...exe file to C:\Program Files\Odeon\JAF\ and make the shortcut of Pkey

    Emulator to your desktop.

8)Now Download the Custom firmware (any of them) From the site and Paste and replace the files

    in your C:\Program Files\Nokia\phoenix\products\RM-XXX\ Folder .

9)A custom firmware mostly includes 3 files (ROFS2 , ROFS3 , UDA) if any of the file is not having

   the name like the original files of your firmware then rename them according to your original

   firmware.

10)Run pkey Emulator from desktop

12) Click OK on the dialog that

      appears, then When J.A.F will

      start

13) Go to 'bb5'tab

14) Make it look almost like the picture below

      (Tick - Manual Flash, Dead USB ) (Untick - 'CRT 308', Normal mode)

15) Tick 'USE INI'

16) Then a list will appear containing all phone models like the picture below

17)Select The phone Which You want to flash and connect it to your pc after Switching it OFF.

18) Click on flash
19) Then Click YES when a dialog appears like on the picture below

20)Now Just press the Power Button on your phone a little (just for about 1 second).

21)Flashing will start and will complete soon and you'll see a DONE msg in JAF window .

22)Now remove the phone and Take our battery and put it back and switch your phone On.

23)And Now you have a Customised Phone.

         NOTE: Instead of process from step 15 you can also use this process

just rename .core.C00 to .c0r first and then untick "use ini" option and then manually select the files
1_MCU:C0r
2_ppm: rofs2
3_CNT: rof3
4_APE.: uda

Many Custom Firmwares are available at These Websites

  1. forum.pnht.pl

  2.forum.dailymobile.com



  Incase of any Problem Just Contact at : 9958123516 or xsumirx@gmail.com. But dont forget that

   by this post I will not be guity. If in any condition your phone dead.

Design your Own remote Control Switch to Control your Home appliances

Hello Guys,

                This is First post in this Blog. Actually, Today I am gonna give you some idea to construct your own Remote Control Switch and Control your Home appliance using your T.V remote or any kind of Infrared remote.

Actually, This is very simple. Alll you have to do Just construct the circuit care fully which is Shown Bellow.

       Circuit a Recieving end for your remote signal. Its use a Simple TSOP1838 sensor which take the I.R rays from the remote when any key is pressed in the remote and make a outpin high for few second that Output is amplified with transistor BC558 and Give the output from its collector to relay Coil and which becomes eneretic for few seconds.
                   Here we are using IC555 in bistable mode and which is triggered for few second simuntenously when relay become energetic and make the output pin3 high for first triggering and Relay 2 coil also become energetic and Still remain in energetic until another trigger pulsr is appllied to NE555 and Hence its works.

           Need any help Contact Here : 9958123516
